Műszaki adatok (angolul):
| SYSTEM SPECIFICATIONS | |
| Frequency Response | 62Hz-20kHz ±3dB (45 Hz – 20 kHz ±3dB with TA-S115 Subwoofer) |
| Usable Frequency Range (-6dB) | 58Hz 21kHz (40 Hz – 21 kHz with TP-S115 Subwoofer) |
| Sensitivity 1W @ 1m | 99 dB SPL Nominal, 97.5 dB SPL Wideband |
| Nominal Peak SPL @ 1m | 129 dB SPL |
| HF Dispersion | 90° Horizontal x 60° Vertical, rotatable horn |
| Crossover Frequency | 1700 Hz passive, with HF protection |
| Nominal Impedance | 8 Ohm |
| Recommended Amplifiers | Trevis Audio TAD1004, TAD1504 |
| PRODUCT FEATURES | |
| Components: Low Frequency | 1 x 12” Neodymium motor 8 Ohm driver |
| 2.5” (64 mm) voice coil | |
| Components: High Frequency | 1 x 1” throat compression driver + low distortion CD horn |
| 1.7” (44 mm) voice coil, polyimide diaphragm, Ferrofluid™ cooling | |
| Connectors | 2 x Neutrik SPEAKON™ 4 pole |
| Construction | Special extreme lightweight plywood cabinet with bracing |
| Height x Width x Depth | 560 x 400 x 360 [mm] |
| Weight | 10.5 kg |
| Handle | Integral, on top of the cabinet |
| Cabinet Finish | Textured durable black polyurethane coating |
| Front finish | AcuFoam™ on perforated steel grille |
| Stand fittings | Built in Stand Fitting, 35mm (1”3/8), 12xM8 flying points |
Hasonló termékek
Adatok
Márka (Brand)
Trevis Audio
Cikkszám
TA-12
