Műszaki adatok (angolul):
|
SYSTEM SPECIFICATIONS |
|
|
Frequency Response |
65Hz-19kHz ±3dB (Fill preset) |
|
Usable Frequency Range (-6dB) |
60Hz – 20kHz (Fill preset) |
|
Max. SPL levels @ 1m |
115 dB SPL (continuous) 121dB SPL(peak) (Fill preset) |
|
Nominal Coverage (-6dB) |
90° Horizontal x 60° Vertical, rotatable HF horn |
|
Crossover Frequency |
2000 Hz bi-amped, DSP processed |
|
Signal Processing |
24 bit/48 kHz, 4 user selectable presets: Front, Fill, Monitor, X-Over |
|
Input Impedance |
10 kOhm, balanced, XLRF input conn., XLRM loop out conn. |
|
Amplifier Rated Power (EIAJ) |
2 channel Class D amplifier with SMPS, LF: 350W, HF:180W |
|
Mains Input & Connectors |
IEC power input socket |
|
Power Requirement |
Nominal: 1 A rms, Peak maximum current draw 3.15 A rms (@230V) |
|
PRODUCT FEATURES |
|
|
Components: Low Frequency |
1 x 8” High power Neodymium motor driver, 2” (51 mm) voice coil |
|
Components: High Frequency |
1 x 1” (25mm) throat compression driver + low distortion CD horn |
|
1.4” (36 mm) voice coil, mylar diaphragm, Ferrofluid™ cooling |
|
|
Construction |
Special extreme lightweight plywood cabinet with bracing |
|
Height x Width x Depth |
410 x 250 x 280 [mm] |
|
Weight |
7.7 kg |
|
Handle |
Integral, on top of the cabinet |
|
Cabinet Finish |
Textured durable black polyurethane coating |
|
Front finish |
AcuFoam™ on perforated steel grille |
|
Stand fittings |
Built in Stand Fitting, 35mm (1”3/8), 12xM8 flying points |
Hasonló termékek
Adatok
Márka (Brand)
Trevis Audio
Cikkszám
TA-08P
